SPECS
| Neck Material: | 5pc Maple/ Walnut |
| Neck Type: | Super Wizard Prestige |
| Body: | Basswood body |
| Frets: | Jumbo frets |
| Fingerboard: | Bound Rosewood |
| Inlay: | Wedge Sharktooth inlay |
| Bridge: | Edge Zero bridge w/ZPS3 |
| NeckPU: | DiMarzio® Air Norton™ Neck |
| MiddlePU: | DiMarzio® True Velvet™ Middle |
| BridgePU: | DiMarzio® Tone Zone® Bridge |
| HW Color: | CK |
| Finishes: | CAB |
FEATURES
| | |
 | The Edge Zero, the newest generation of Edge knife-edge tremolos, employs design advantages from the high tech ZR Zero Resistance trem such as the Zero Point System, an onboard intonation screw and arm torque adjustment. |
| | |
 | RG3770Z is stocked with DiMarzio® Air Norton™ (H) neck, DiMarzio® True Velvet™ (S) mid, and DiMarzio® Tone Zone® (H) bridge pickups. |
| | |
 | RG3770Z is ready to fire with a Prestige Super Wizard HP 5-pc Maple/Walnut neck. Fast and thin, this neck offers great grip, feel and tone. |
| EDGE-ZERO TREMOLO |
 |
| The Edge-Zero, a new generation of Ibanez tremolo knife, deploys all unique features of the ZR trem. Locking pins to contribute to the stability of adjustment. |
FEATURES
| | |
 | Trems Edge-Zero is standard on all RG Prestige, RG3000 and RGA Prestige models. |
| | |
 | Rear view of the Edge Zero bridge with string system that allows radical trem effects ZPS3 with flawless precision adjustment. |
| | |
 | Just unscrew the built-in tool for setting the tone of the base and screw it into the bottom of each saddle for quick adjustment. |
| | |
 | The latch is offset from the center of the saddle, which allows easy access to the screw without loosening the strings. |
RG PRESTIGE SERIES BASICS
- Precision-made in Japan by Ibanez’s finest luthiers
- Super Wizard neck features the legendary ultra-thin, ultra-flat Wizard 17mm neck dimensions, but with 5-pc construction and KTS™ Titanium reinforcement rods for even greater strength (RG3000 series models)
- RG Prestige fixed bridge models feature Tight-End bridge for maximum string vibration
- RG3000 series models feature genuine made-in-USA DiMarzio® pickups
- 6-, 7-, and 8-string models available
- Includes deluxe Prestige case (most models)
NECK DIMENSIONS
 |
| ||||||||||||||||||
PICKUPS
| Bridge Pickup | |
| Name: | DiMarzio® Tone Zone® |
| Model No: | DP155 |
| Construction: | Humbucking |
| Magnet: | Alnico |
| Description: | Hot enough to qualify as a pick-up high-yielding, but has a wider dynamic range - hard picking produce much power, and softer picking will be much cleaner and quieter. |
| | |
| Middle Pickup | |
| Name: | DiMarzio® True Velvet™ |
| Model No: | DP175S |
| Construction: | Single Coil |
| Magnet: | Alnico |
| Description: | A pickup vintage single coil that is clean and bright, but always designed for soft noise when taking over the 12th fret. Coil is tuned to a frequency range that is bright but not thin. |
| | |
| Neck Pickup | |
| Name: | DiMarzio® Air Norton™ |
| Model No: | DP193 |
| Construction: | Humbucking |
| Magnet: | Alnico |
| Description: | The tone is deep and warm but not muddy. It's hot, but not distorted. There are even cool harmonics, which are really unusual for a neck humbucker. |
SWITCHING SYSTEM
 |
